M6 SS Countersunk Machine Screw
M6 stainless steel flat-head machine screws to DIN 965 / ISO 7046 with Phillips/Pozi drive in A2-70 grade. 90° countersunk head for flush installation at 6mm diameter.
Specification
#
Standard
ISO 7046 / DIN 965
Thread
Coarse (standard)
Material
Stainless Steel 304 (A2)
Grade
A2-70
Stock
In stock (304). Grade 316 available against bulk order
Dimension
#
Size (d mm)
Thread Dia (min-max mm)
Pitch
Length (mm)
Thread Length (mm)
M3
2.98-3.00
0.5
6-30
Full thread
M4
3.97-4.00
0.7
8-40
Full thread
M6
5.97-6.00
1.0
10-60
Full thread
M8
7.96-8.00
1.25
12-80
Full thread
M10
9.96-10.00
1.5
16-100
Full thread
- All dimensions in mm, tolerance +/- 0.01 mm. Additional dimensions available on request.
Benefits
#
At 6mm, stainless steel countersunk machine screws enable flush surfaces in corrosive service. The 90° head angle matches standard countersink tooling, simplifying hole preparation. A2 stainless steel construction is appropriate for atmospheric exposure and hygienic environments. Phillips and Pozi drive compatibility ensures installation flexibility across hand and powered assembly operations.
Common Applications
#
Typical applications for 6mm stainless steel countersunk machine screws:
- Architectural metalwork flush panels
- Aerospace interior panels
- Machinery guard flush mounting
- Industrial equipment covers
- Signage and display mounting
Read Me
| Standard | ISO 7046 / DIN 965 |
| Thread | Coarse (standard) |
| Material | Stainless Steel 304 (A2) |
| Grade | A2-70 |
| Stock | In stock (304). Grade 316 available against bulk order |
| Size (d mm) | Thread Dia (min-max mm) | Pitch | Length (mm) | Thread Length (mm) |
|---|---|---|---|---|
| M3 | 2.98-3.00 | 0.5 | 6-30 | Full thread |
| M4 | 3.97-4.00 | 0.7 | 8-40 | Full thread |
| M6 | 5.97-6.00 | 1.0 | 10-60 | Full thread |
| M8 | 7.96-8.00 | 1.25 | 12-80 | Full thread |
| M10 | 9.96-10.00 | 1.5 | 16-100 | Full thread |
