M10 SS Round Head Machine Screw
ISO 1207 M10 stainless steel cheese head screws in A2 (304) grade with slotted drive. Narrow cylindrical head occupies minimal lateral space at 10mm thread diameter.
Specification
#
Standard
ISO 1207 / DIN 84
Thread
Coarse (standard)
Material
Stainless Steel 304 (A2)
Grade
A2-70
Stock
In stock (304). Grade 316 available against bulk order
Head Type
Round head (cheese head)
Drive Type
Slotted
Thread Tolerance
6g per ISO metric standards
Finish
Plain/Passivated (stainless steel)
Dimension
#
Size (d mm)
Thread Dia (min-max mm)
Pitch
Length (mm)
Thread Length (mm)
M3
2.98-3.00
0.50
10
10
M4
3.98-4.00
0.70
12
12
M5
4.98-5.00
0.80
16
16
M6
5.97-6.00
1.00
20
20
M8
7.97-8.00
1.25
25
25
- All dimensions in mm, tolerance +/- 0.01 mm. Additional dimensions available on request.
Benefits
#
The 10mm stainless steel round head machine screw addresses fastening in crowded panels where wider head profiles cannot fit between adjacent components. A2-70 grade provides 700 MPa tensile strength with inherent corrosion protection. The slotted drive eliminates the need for specialized driver bits. Simple head geometry keeps manufacturing costs lower than cross-recessed alternatives, making these screws economical for high-volume light-duty assemblies.
Common Applications
#
M10 SS round head machine screws are specified for space-constrained corrosion-resistant fastening:
- Electrical panels and switchgear
- Light-duty machinery assembly
- Instrumentation control panels
- Lighting fixture mounting
- Vintage equipment restoration
Read Me
| Standard | ISO 1207 / DIN 84 |
| Thread | Coarse (standard) |
| Material | Stainless Steel 304 (A2) |
| Grade | A2-70 |
| Stock | In stock (304). Grade 316 available against bulk order |
| Head Type | Round head (cheese head) |
| Drive Type | Slotted |
| Thread Tolerance | 6g per ISO metric standards |
| Finish | Plain/Passivated (stainless steel) |
| Size (d mm) | Thread Dia (min-max mm) | Pitch | Length (mm) | Thread Length (mm) |
|---|---|---|---|---|
| M3 | 2.98-3.00 | 0.50 | 10 | 10 |
| M4 | 3.98-4.00 | 0.70 | 12 | 12 |
| M5 | 4.98-5.00 | 0.80 | 16 | 16 |
| M6 | 5.97-6.00 | 1.00 | 20 | 20 |
| M8 | 7.97-8.00 | 1.25 | 25 | 25 |
